LIQUID LEVEL TRANSMITTER – EMERSON – ROSEMOUNT™ – ALPHALINE® – SERIE 1151LT – MODEL 1151LT5SA4E22DT10004L4C6
Additional information
| Condition | |
|---|---|
| Manufacturer | |
| Modele | |
| Site |
ROSEMOUNT 1151LT TRANSMITTER MODEL NUMBERING SPECIFICATION :
- TRANSMITTER TYPE FOR MODEL 1151LT : LIQUID LEVEL TRANSMITTER
- PRESSURE RANGES TYPE 5 : 750 inH2O (0–3,175 to 0–19,050 mmH2O)
- TRANSMITTER OUTPUT TYPE E : 4–20 mA, LINEAR WITH INPUT
- SIZE TYPE A4 : 3 in./DN 80
- MATERIAL TYPE A4 : 316L SST
- EXTENSION LENGTH TYPE A4 : 4 in./100 mm
- PRODUCT CERTIFICATIONS TYPE C6 : CSA EXPLOSION-PROOF, INTRINSICALLY SAFE
MOUNTING FLANGE :
- SIZE : 3-IN.
- RATING : CLASS 600
- MATERIAL : CS
- DIAPHRAGM SIZE : 3 IN./DN 80
SENSOR MODULE AND LOW-SIDE MATERIALS OF CONSTRUCTION TYPE 22 :
- LOW-SIDE FLANGE AND ADAPTER : 316 SST
- DRAIN/ VENT VALVES : 316 SST
- LOW-SIDE ISOLATOR DIAPHRAGM : 316L SST
- LOW-SIDE FLUID FILL : SILICONE
OTHER SPECIFICATIONS :
- MAX WORKING PRESSURE : 275 PSI
- MAX SUPPLY VOLT DIRECT CURRENT (VDC) : 42.4 V
